Product WLC90WGL30RPWMQ
LED Area Light
In the Metal Housing
Order number: 3092442Alternative order number : 92442
- Operating voltage: 12…30 VDC
- Protection class IP67/IP69K
- Ambient temperature: -40 °C…+70 °C
- Window material: borosilicate glass
- Opening angle: 30°
- Mounted via 4 × 1/4”-20 UNC screws
- Color: White
- Internal temperature regulation
- Dimmable via PWM input
General data
| EAN | 662488924423 |
| eCl@ss-Code (V5.1.4): | 27119002 -/- Work light |
| Customs tariff number | 94054239900 |
| Country of origin | US |
| Weight | 508 g |
Technical Data
| Electrical connection | Connector |
| Protection class | IP67/IP68/IP68 |
Mounting accessories
|
PDP-TRA
PROFIBUS-DP terminating resistor, 1 x M12 male, B-coded, 5-pin, active, feeding via 1 x 7/8” male, 5-pin |
6825346 |
|
RSSD-PSGS4M-4422-1M | 6635159 |
