Product RM-28S6C-3C25B-H1181
Absolute Rotary Encoder - Multiturn
Industrial Line
Order number: 1545238- Clamping flange, Ø 58 mm
- Solid shaft, Ø 6 mm × 10 mm
- Optical measuring principle
- Shaft material: stainless steel
- IP67 rated on shaft side
- -40…+70 °C
- Max. 9000 rpm
- 10…30 VDC
- SSI, gray
- M12 connector, 8-pin
- Singleturn, 13-bit resolution
- Multiturn, 12-bit resolution
General data
| EAN | 4047101268614 |
| eCl@ss-Code (V5.1.4): | 27270501 -/- Encoder, absolute |
| Customs tariff number | 90314990000 |
| Country of origin | DE |
| Weight | 572 g |
Connectivity accessories
|
TL50RALSQP | 3016693 |
Connectivity accessories — Power supply
|
PKG4M-1.5-PSG3M/TEL | 6626415 |
|
Q7LMEB W/15 | 3086320 |
