Product BI1.5-EH6.5-AP6X-V1131
Inductive Sensor
Order number: 4612020- Smooth barrel, Ø 6.5 mm
- Stainless steel, 1.4305 (AISI 303)
- DC 3-wire, 10…30 VDC
- NO contact, PNP output
- M8 x 1 male connector
General data
| EAN | 4047101155464 |
| eCl@ss-Code (V5.1.4): | 27270101 -/- Inductive proximity switch |
| Customs tariff number | 85365019000 |
| Country of origin | LK |
| Weight | 8 g |
Technical Data
| Design | Smooth barrel |
| Construction size | Ø 6.5 mm |
| Operating voltage | 10…30 VDC |
| Switching element function | NO contact |
| Output function | PNP |
| Electrical connection | Connector, M8 × 1 |
| Housing material | Stainless steel, 1.4305 (AISI 303) |
| Ambient temperature | -25…+70 °C |
| Protection class | IP67 |
Mounting accessories
|
VAS22-S80E-0.3-RSC5.31T/TXL | 6606506 |
|
TN840/920-Q175L200-H1147 | 7030466 |
|
SLSCR14-1050Q8 | 3072422 |
Connectivity accessories
|
K50APT2YRCQP | 3800873 |
|
Q50AP W/30 | 3067617 |
