Product TL50BLGYRQP

Zoom

LED Signal Light

Tower Light

Order number: 3019288

Alternative order number : 19288

Black plastic housing
Protection class IP67
EMI and RFI immune

Multicolor: Green (COL 1) / Yellow (COL 2) / Red (COL 3)

Operating voltage: 12…30 VDC or 24 VAC with 45 mA per LED color
Inputs: PNP/NPN

Hide All Open All

Specifications
Download
Accessories

General data

EAN	662488192884
eCl@ss-Code (V5.1.4):	27371201 -/- Indicator
Customs tariff number	85318070000
Country of origin	US
Weight	185 g

Technical Data

Operating voltage	21…27 VAC / 12…30 VDC
Electrical connection	Cable with connector, M12 × 1
Cable length	0.150 m
Housing material	Plastic, ABS, Black
Ambient temperature	-40…+50 °C
Protection class	IP67

Data Sheets

German	422 KB
English	421 KB
French	422 KB
Spanish	422 KB
Czech	422 KB
Dutch	420 KB
Romanian	421 KB
Russian	339 KB
Polish	423 KB
Chinese	495 KB
Turkish	423 KB

General Catalog

LED solutions	14775 KB

Product Flyer

Selection Guide — Lighting and Indicators	4409 KB

Connectivity accessories

	TI-BL20-E-EN-S-6 BL ident interface set	7030632
	RSC4.4T-15/TXG	6634164
	PT300PSIG-2014-U1-DA91/X	6837037

Functional accessories

	RKP56PLB-10-RSP56PLB/TXG	100003349
	PKG4M-10/TEG	6628554
	RKC4T-P7X2-10-RSC4T/TEL	6625413
	PS001D-502T-2UPN8X-H1141	6834112
