Product RKCV4.4T-5-RSCV4.4T/TXL1001
Weld-Splatter Resistant Actuator and Sensor Cable
Extension Cable
Order number: 6629255- Female M12, straight, 4-pin
- Stainless steel coupling nut/screw
- M12 male, straight, 4-pin
- Jacket material: PUR jacketed with aramid fibers
- Jacket color: yellow
- Resistant to welding sparks
- Flame retardant
- Resistant to chemicals, UV radiation and oils
- Free from halogen, silicone, PVC and LABS
- Protection class: IP67, IP69K
- Protective jacket material: aramid fibers
- Tensile strength: 2923 MPa
- Breaking strength: 333 N
- Elongation at break: 3.6 %
- Temperature peaks: up to +200 °C
- Cable length: 5.0 m
General data
| EAN | 4047101346244 |
| eCl@ss-Code (V5.1.4): | 27250107 -/- Connection cable sensor-actuator |
| Customs tariff number | 85444290900 |
| Country of origin | CN |
| Weight | 183 g |
Technical Data
| Cable length | 5.0 m |
| Ambient temperature | -30…+90 °C |
Mounting accessories
|
DWE-30000-135-10-2B4000-H1181 | 100049412 |
|
PT300PSIG-1003-U1-DA91 | 6836998 |
|
BSM-30
Mounting clip for inductive couplers, smooth and threaded barrel sensors; material: aluminum |
100047196 |
|
JBBS-48SC-T415B/EX | 6611417 |
|
Q40SN6LP W/30 | 3033898 |
|
PKG4S-10/TEL | 6627372 |
|
EC-FKD5-0.5/16 | 6934608 |
|
BMEL1816A
Photoelectric sensor, series MINI-ARRAY, sensing mode: light screen, 0.9 -17 m sensing range, rectangular housing with connector, 16-30 VDC supply voltage, separately configurable outputs, emitter |
3039574 |
Connectivity accessories
|
FAS4-CSG43 | 6821322 |
|
PS025R-501-2UP8X-H1141 | 6831840 |
|
IMX12-AI01-2I-2IU-HPR/24VDC
Isolating transducer; 2-channel; power supply of passive 2-wire isolating transducers with HART |
7580304 |
|
BL67-B-1M12
For use with 1RS23 and 1RS485/422 with 1 x M12 connection, 5-pole |
6827185 |
|
REI-05I6E-4A1024-H1181 | 100011218 |
|
PKG4M-1-PKW4M/TEL | 6633158 |
|
SLPMR14-1810 | 3084474 |
|
QS186EQ7 | 3066425 |
|
TB-8M8Z-3-5 | UX09109 |
|
TI-BL20-E-EN-S-6
BL ident interface set |
7030632 |
Functional accessories
|
RKP56PLB-10-RSP56PLB/TXG | 100003349 |
