Product PBT46UC
Plastic Fiber
Bifurcated Fiber
Order number: 3026086Alternative order number : 26086
- Operation: diffuse/opposed mode
- Polyethylene sheath, flexible
- Operating temperature: -30…+70 °C
- Coiled, customizable cable
- End sleeve for sensor: Thread
- Optical fiber, core diameter 1.0 mm
- Optical fiber, total length: ± 1829 mm
General data
| EAN | 662488260866 |
| eCl@ss-Code (V5.1.4): | 27061090 -/- Ready-made optical fiber (not classified) |
| Customs tariff number | 85447000900 |
| Country of origin | JP |
| Weight | 65 g |
Technical Data
| Construction size | 1828 mm |
| Housing material | Plastic, PE, Black |
| Ambient temperature | -30…+70 °C |
Connectivity accessories
|
PT4R-2004-U1-H1143 | 100048487 |
|
RSSD-RSSD-4422-18M | 6635887 |
