Product BI2-M08E-VP6X-H1341
Inductive Sensor
With Increased Switching Distance
Order number: 4602961- Threaded barrel, M8 x 1
- Nickel-plated brass
- Large sensing range
- DC 4-wire, 10…30 VDC
- Changeover contact, PNP output
- M12 x 1 male connector
General data
| EAN | 4047101411713 |
| eCl@ss-Code (V5.1.4): | 27270101 -/- Inductive proximity switch |
| Customs tariff number | 85365019000 |
| Country of origin | PL |
| Weight | 20 g |
Technical Data
| Design | Threaded barrel |
| Construction size | M8 x 1 |
| Operating voltage | 10…30 VDC |
| Switching element function | Complementary contact |
| Output function | PNP |
| Electrical connection | Connector, M12 × 1 |
| Housing material | Metal, CuZn, Nickel Plated |
| Ambient temperature | -25…+70 °C |
| Protection class | IP67 |
| Special features | Sn + |
Mounting accessories
|
AIH401-N | 6884269 |
|
BI1.5-EG08-AP6X
Cylindrical, threaded barrel, 8 mm, stainless steel |
4602240 |
Functional accessories
|
FKFD54PL-1/M16 | 100028353 |
|
PSWH4M-10/TFG | 6933497 |
|
INS.P.ULTRASONIC-RU_HIGH_END.ES | D102294 |
|
PS001D-502T-2UPN8X-H1141 | 6834112 |
