Product QM42VP6FP W/30'
Photoelectric Sensor
Photoelectric Sensor for Plastic Fibers
Order number: 3073308- Cable, PVC, 2 m, 4-wire
- Metal housing, ZN, black
- Protection class IP67
- Sensitivity adjusted via potentiometer
- Operating voltage 10…30 VDC
- PNP switching output
- Light/dark operation
General data
| eCl@ss-Code (V5.1.4): | 27270905 -/- Fiber optic sensor |
Technical Data
| Function | Fiber optic sensor |
| Light type | Red |
| Output function | NO/NC, PNP |
| Electrical connection | Cable |
| Cable length | 2.0 m |
| Housing material | Metal, ZN, Black-finished |
| Ambient temperature | -20…+70 °C |
| Protection class | IP67 |
Connectivity accessories
|
K50APT2YRCQP | 3800873 |
|
Q50AP W/30 | 3067617 |
