Product BMWS8251-0/9
Field-Wireable Connector
Female Connector M12 × 1, Angled
Order number: 6904713- For use in PROFIBUS-DP applications
- Up to 12 Mbps
- Shielding via iris spring connection
- B-coding
- Metal housing
- Screw-clamp terminal
- 5-pin
- PG9 screw-in thread
- Cable feedthrough 6.0…8.0 mm

General data
| EAN | 4047101458503 |
| eCl@ss-Code (V5.1.4): | 27279201 -/- Connectivity (accessories sensors) |
| Customs tariff number | 85366990990 |
| Country of origin | DE |
| Weight | 71 g |
Data Sheets
| German | 1021 KB |
| English | 1021 KB |
| French | 1023 KB |
| Spanish | 1020 KB |
| Czech | 1022 KB |
| Dutch | 1022 KB |
| Romanian | 1022 KB |
| Russian | 1027 KB |
| Polish | 1022 KB |
| Turkish | 1022 KB |
Approval/Declaration
| UL Approval | 400 KB |
| CE Declaration of Conformity | 120 KB |
| RoHS and REACH Manufacturer's Declaration | 280 KB |
