Product SL10VB6V W/30
Photoelectric Sensor
Bifurcated Retroreflective Sensor
Order number: 3058327Alternative order number : 58327
- Cable, PVC, 9 m, 5-wire
- Protection class IP67
- Slot width 10 mm
- Sensitivity adjusted via potentiometer
- Operating voltage: 10…30 VDC
- Switching output, bipolar
- Light or dark operation via grey core / PIN 5 adjustable
General data
| EAN | 662488583279 |
| eCl@ss-Code (V5.1.4): | 27270909 -/- Slot sensor |
| Customs tariff number | 85365019000 |
| Country of origin | CN |
| Weight | 625 g |
Technical Data
| Function | Slot sensor |
| Light type | Red |
| Output function | NO contact, PNP/NPN |
| Electrical connection | Cable |
| Cable length | 9.0 m |
| Housing material | Plastic, Thermoplastic material, Black |
| Window material | Plastic |
| Ambient temperature | -40…+70 °C |
| Protection class | IP67 |
