Product IA23S
Glass Fiber
Single Conductor
Order number: 3017299Alternative order number : 17299
- Operating mode: Opposed mode sensor
- Stainless steel jacket, flexible
- Operating temperature of fiber-optic jacket: -140…+249 °C
- End sleeve for sensor: Stainless steel, angled (90 °)
- Operating temperature of fiber-optic tip: -140…+249 °C:
- Optical fiber, bundle diameter: 3.2 mm
- Optical fiber, total length: ± 914 mm
General data
| EAN | 662488172992 |
| eCl@ss-Code (V5.1.4): | 27061090 -/- Ready-made optical fiber (not classified) |
| Customs tariff number | 90011090900 |
| Country of origin | US |
| Weight | 110 g |
Technical Data
| Function | Opposed mode sensor (emitter/receiver) |
| Design | Circular |
| Housing material | Stainless steel |
| Ambient temperature | -140…+249 °C |
Connectivity accessories
|
TI-BL20-E-EN-S-6
BL ident interface set |
7030632 |
|
RSC4.4T-15/TXG | 6634164 |
Functional accessories
|
TL502AKQ | 3804943 |
