Product IMXK12-AO01-1I-1I-H0/24VDC
Analog Signal Isolator
1-channel
Order number: 100000703- Input circuit monitored for wire break and short circuit
- Complete galvanic isolation
- HART transparent
- Removable screw terminals
- ATEX, IECEx, cULus
- Use in zone 2
- SIL 2
General data
| EAN | 4047101441727 |
| eCl@ss-Code (V5.1.4): | 27210107 -/- Transducer (universal) |
| Customs tariff number | 85437090990 |
| Country of origin | DE |
| Weight | 121 g |
Technical Data
| Housing material | Plastic, Polycarbonate/ABS |
| Ambient temperature | -25…+70 °C |
| Protection class | IP20 |
Data Sheets
| German | 273 KB |
| English | 273 KB |
| French | 274 KB |
| Spanish | 274 KB |
| Czech | 274 KB |
| Dutch | 273 KB |
| Romanian | 273 KB |
| Russian | 984 KB |
| Polish | 274 KB |
| Chinese | 341 KB |
| Turkish | 326 KB |
Approval
| TÜV 15 ATEX 153600 X | 1520 KB |
| IECEx - TUN15.0011X | 2327 KB |
| UL - IS-1.318A1 | 168 KB |
| SIL TÜV Certificate | 888 KB |
| TÜV 22 UKEX 7101 X | 356 KB |
EU Declaration of Conformity
Product Catalog
Quick Start Guide
Safety Manual
Technology Flyer
Mounting accessories
|
REI-E-113T8S-2B2500-H1181 | 100011551 |
|
RSS8T-5/TEL | 6625453 |
|
PKG4M-1-PSW4M/TEL | 6625316 |
Connectivity accessories
|
TI-BL20-E-EN-S-6
BL ident interface set |
7030632 |
|
RSC4.4T-15/TXG | 6634164 |
