Product MIAD9FQ
Photoelectric Sensor
Photoelectric Sensor for Glass Fibers
Order number: 3034626Alternative order number : 34626
- Metallic optical fibers must be grounded
- M12 × 1 connector, 4-pin
- Degree of protection IP67
- Sensitivity adjusted via potentiometer
- Alignment indicator
- Operating voltage: 5…15 VDC (NAMUR)
- NAMUR output in accordance with DIN 19234 (IEC/EN 60947-5-6)
- ATEX category II 1 G, Ex zone 0
General data
| EAN | 662488346263 |
| eCl@ss-Code (V5.1.4): | 27270905 -/- Fiber optic sensor |
| Customs tariff number | 85365019000 |
| Country of origin | US |
| Weight | 57.61 g |
