Product SDPB-40A-0004
piconet stand-alone module for PROFIBUS-DP
4 Analog Inputs for Thermoelements
Order number: 6824050- 4 analog inputs for thermoelements
- Configuration interface
- Parameterizable functions
- Supported via I/O‐ASSISTANT 2
- Direct connection to the fieldbus
- Fibre-glass reinforced housing
- Shock and vibration tested
- Encapsulated module electronics
- Metal connector
- Degree of protection IP67
General data
| EAN | 4047101177756 |
| eCl@ss-Code (V5.1.4): | 27250303 -/- Analog I/O module |
| Customs tariff number | 85176200000 |
| Country of origin | DE |
| Weight | 249 g |
Technical Data
| Network protocol | PROFIBUS-DP |
| Approvals | cULus |
