Product PVA375P6
Pick-to-Light
Placement Sensor
Light Grid Kit
Order number: 3052913Alternative order number : 52913
- Scan field L2: 375 mm
- 16-beam system, beam spacing 25 mm
- Emitter / Receiver
- Range max. 2 m
- Light / Dark operation
- Selectable frequency as protection against crosstalk
- Operating voltage 12…30 VDC
- PNP switching output of the receiver
- Input of operation request light +24 VDC
- Protection class IP62
General data
| EAN | 662488529130 |
| eCl@ss-Code (V5.1.4): | 27270910 -/- Light grid |
| Customs tariff number | 85365019000 |
| Country of origin | US |
| Weight | 883 g |
Technical Data
| Cable length | 2.0 m |
