Product LT7PLVQ
Photoelectric Sensor
Retroreflective Laser Sensor (Runtime Measurement)
With Switching Outputs
Order number: 3073440Alternative order number : 73440
- Male M16 x 0.75, 12-pin
- Indication of signal intensity
- Laser class 1, infrared, 900 nm
- Alignment aid during programming, laser class 2, visible red, 650 nm
- LCD display
- Operating voltage: 18…30 VDC
- Two independently adjustable switching outputs
- Alarm output
- Serial interface RS422 or SSI compatible
General data
| EAN | 662488734404 |
| eCl@ss-Code (V5.1.4): | 27270801 -/- Optical distance sensor |
| Customs tariff number | 85365019000 |
| Country of origin | DE |
| Weight | 344 g |
Mounting accessories
|
PS01VR-501-2UP8X-H1141 | 6831832 |
|
INS.P.FLOW-FCS_N1_2A4_NAEX.01 | D102316 |
Connectivity accessories
|
TCG20-CC
Replacement connector for CAN interface. |
100002936 |
