Product CABLE 572-500M
Bus Cable for CAN (DeviceNet, CANopen)
PVC Cable Jacket, Thin
Order number: 6604900- Jacket material: PVC
- Power pair: AWG 2/22
- Data pair: AWG 2/22
- Jacket color: gray
- UL approval
- Cable length: 500 m
General data
| EAN | 4047101040623 |
| eCl@ss-Code (V5.1.4): | 27060307 -/- Bus cable |
| Customs tariff number | 85444995900 |
| Country of origin | US |
| Weight | 35800 g |
Technical Data
| Application | Data |
| Network protocol | DeviceNet, CANopen |
| Voltage | 300 V |
| Current | 4 A |
| Cable diameter | Ø 7.2 mm |
| Cable length | 500.0 m |
| Cable jacket | PVC, Gray |
| Number of Conductors | 2 |
| Approvals | UL, CSA |
Mounting accessories
|
PS01VR-501-2UP8X-H1141 | 6831832 |
|
INS.P.FLOW-FCS_N1_2A4_NAEX.01 | D102316 |
Connectivity accessories
|
TCG20-CC
Replacement connector for CAN interface. |
100002936 |
