Product D10AFPGY
Photoelectric Sensor
Photoelectric Sensor for Plastic Fibers
Order number: 3073124Alternative order number : 73124
- Cable 2 m
- Light/dark operation
- Green visible light
- Operating voltage 10…30 VDC
- Switch-off delay 40 ms, selectable
- Max. switching frequency 2.5 kHz
- Sensitivity adjusted via 12-turn potentiometer
General data
| EAN | 662488731243 |
| eCl@ss-Code (V5.1.4): | 27270905 -/- Fiber optic sensor |
| Customs tariff number | 85365019000 |
| Country of origin | CN |
| Weight | 100 g |
Technical Data
| Design | Rectangular |
| Operating voltage | 10…30 VDC |
| Electrical connection | Cable |
| Cable length | 2.0 m |
| Housing material | Plastic, Thermoplastic material, Black |
| Ambient temperature | -20…+55 °C |
| Protection class | IP50 |
Connectivity accessories
|
SMU315DQDP | 3059144 |
