Product LM150KUQP
Photoelectric Sensor
Laser Sensor, Diffuse Mode (Triangulation)
Order number: 3810151- Stainless steel housing
- Protection class IP67
- Connection via 300 mm cable with connector, M12 × 1, 5-pin
- Laser class 2
- Visible red, 655 nm
- Analog output accuracy: 0,004 mm
- IO-Link accuracy: 0.2 mm
- Range: 50…150 mm
- Operating voltage: 10…30 VDC
- Push/pull switching output or IO-Link
- Analog output 0…10 V
General data
| EAN | 662488083151 |
| eCl@ss-Code (V5.1.4): | 27270801 -/- Optical distance sensor |
| Customs tariff number | 85365019000 |
| Country of origin | US |
| Weight | 209 g |
Technical Data
| Design | Rectangular |
| Operating voltage | 10…30 VDC |
| Voltage output | 0…10 V |
| Communication protocol | IO-Link |
| Electrical connection | Cable with connector, M12 × 1 |
| Cable length | 0.30 m |
| Housing material | Stainless steel, 1.4404 (AISI 316L), Grey |
| Ambient temperature | -10…+55 °C |
| Protection class | IP67 |
