Product FCS-GL1/2A4P-VRX/24VDC
Flow Monitoring
Immersion Sensor with Integrated Processor
Order number: 6870097- Sensor for liquid media
- Calorimetric principle
- Adjustment via potentiometer
- Status indicated via LED chain
- 5‐wire DC, 19.2…28.8 VDC
- Changeover contact, relay output
- Cable device
General data
| EAN | 4047101171976 |
| eCl@ss-Code (V5.1.4): | 27273190 -/- Flow meter (not classified) |
| Customs tariff number | 90261029000 |
| Country of origin | DE |
| Weight | 601 g |
Technical Data
| Cable length | 2.0 m |
Mounting accessories
|
PS01VR-501-2UP8X-H1141 | 6831832 |
