Product IM36-22EX-U
Potentiometer Amplifier
2-channel
Order number: 7509530- Transmission of potentiometer signals from the Ex area
- Potentiometer, nominal resistance: 0.8…100 kΩ
- Output circuit: 0…10 V
- Complete galvanic isolation
- Input reverse-polarity protected
- ATEX, IECEx, TR CU, KOSHA
- Installation in zone 2
General data
| EAN | 4047101118032 |
| eCl@ss-Code (V5.1.4): | 27210120 -/- Input/output isolator |
| Customs tariff number | 85369095000 |
| Country of origin | DE |
| Weight | 204 g |
Technical Data
| Signal type | Resistance input |
| Device type | Potentiometer |
| Ex version | yes |
| Approvals | ATEX, IECEx, TR CU |
| Nominal voltage | Wide voltage range |
| Number of channels | 2 |
| Electrical connection | 4 × 5-pin removable terminal blocks, reverse polarity protected, screw terminal |
| Protection class | IP20 |
| Product series | IM |
Data Sheets
| German | 243 KB |
| English | 241 KB |
| French | 241 KB |
| Spanish | 242 KB |
| Czech | 243 KB |
| Dutch | 240 KB |
| Romanian | 241 KB |
| Russian | 262 KB |
| Polish | 242 KB |
| Chinese | 300 KB |
| Turkish | 242 KB |
Approval
| TÜV 12 ATEX 093477 | 1417 KB |
| TÜV 12 ATEX 093479X | 1461 KB |
| IECEx — TUN 12.0026X | 336 KB |
| KOSHA 14-AV4BO-0479X | 373 KB |
EU Declaration of Conformity
Product Catalog
Product Flyer
Quick Start Guide
Technology Flyer
Mounting accessories
|
IM-CC-5X2BU/2BK
Cage clamp terminals for IM modules (Ex-devices with 27 mm overall width); includes: 2 pcs. 5-pin blue terminals and 2 pcs. 5-pin black terminals. |
7504031 |
Connectivity accessories
|
IM-SC-5X2BU/2BK
Screw terminals for IM modules (non-Ex devices with 27 mm overall width); includes: 4 × 5-pin black terminals. |
7541214 |
