Product QS18EP6DBQ5
Photoelectric Sensor
Diffuse Mode Sensor
Order number: 3068758Alternative order number : 68758
- Cable with male end, M12 × 1, 4-pin, PVC, 150 mm
- Protection class IP67
- LED all-round visible
- Sensitivity adjusted via teach button
- Operating voltage: 10…30 VDC
- PNP switching output
- Light or dark operation
General data
| EAN | 662488687588 |
| eCl@ss-Code (V5.1.4): | 27270903 -/- Diffuse mode sensor, energy-efficient |
| Customs tariff number | 85365019000 |
| Country of origin | US |
| Weight | 59 g |
Technical Data
| Cable length | 0.150 m |
