Product RI360P1-QR14-ELIU5X2
Miniature Encoder
With Analog Output
Premium Line
Order number: 1590853- Rectangular, plastic
- Many mounting possibilities
- P1-Ri-QR14 included in delivery
- Measuring range displayed via LED
- Immune to electromagnetic interference
- Resolution, 12-bit
- 4‐wire, 15…30 VDC
- Analog output
- Programmable measuring range
- 0…10 V and 4…20 mA
- Cable connection
General data
| EAN | 4047101274318 |
| eCl@ss-Code (V5.1.4): | 27270501 -/- Encoder, absolute |
| Customs tariff number | 90318080000 |
| Country of origin | DE |
| Weight | 136 g |
Technical Data
| Ambient temperature | -25…+70 °C |
| Protection class | IP68/IP69K |
