Product RSFV 48
PROFIBUS-PA Receptacle
Front-Mounted
Order number: U7895- Male 7/8" minifast receptacle
- 1/2’’14 NPT screw-in thread
- Stainless steel receptacle housing
- 4-pin, solderable
- For use in PROFIBUS-PA applications
General data
| EAN | 4047101040418 |
| eCl@ss-Code (V5.1.4): | 27250314 -/- Connection technology |
| Customs tariff number | 85444290900 |
| Country of origin | MX |
| Weight | 54 g |
Technical Data
| Application | Data |
| Network protocol | PROFIBUS-PA |
| Approvals | FM Div.2, CSA Div. 2, CSA C22.2 No. 182.3, CE, RoHS, UL Listed, UL 2238 |
