Product R58BPCRGB2
Photoelectric Sensor
Color Mark Sensor
With Switching Output
Order number: 3015654Alternative order number : 15654
- Cable, PVC, 2 m, 5-wire
- Protection class IP67
- Programmed via 2 teach buttons
- Detects extremely small differences in contrast
- Adjustable on/off delay, 30 ms
- Automatic selection of red, green and blue light
- Orthogonal scan field relative to longitudinal housing axis
- Optics rotatable by 90°
- Operating voltage: 10…30 VDC
- PNP switching output
- Switching behavior adjustable (NO/NC)
- Teach input
General data
| EAN | 662488156541 |
| eCl@ss-Code (V5.1.4): | 27270906 -/- Color mark sensor |
| Customs tariff number | 85365019000 |
| Country of origin | CN |
| Weight | 545 g |
Technical Data
| Cable length | 2.0 m |
