Product R45C-K-UUQ
Converter
Order number: 3812256- Protection classes IP67, IP68
- Flat, compact housing
- In-line mounting
- Operating voltage: 18…30 VDC
- Input: analog, 0…10 V
- Output: IO-Link, 0…10 V
- Converts the voltage signal into 16-bit process data
General data
| EAN | 662488112349 |
| Customs tariff number | 85176200000 |
| Country of origin | US |
| Weight | 78.47 g |
Technical Data
| Design | Rectangular |
| Communication protocol | IO-Link |
| Electrical connection | Connector, M12 × 1 |
| Housing material | Plastic, PVC, Black |
| Ambient temperature | -40…+70 °C |
| Protection class | IP67/IP68 |
Mounting accessories
|
TL50WBGYRTAKQ | 3801296 |
|
PT40R-1004-U1-H1143 | 6836476 |
Connectivity accessories
|
TI-BL20-E-EN-S-6
BL ident interface set |
7030632 |
|
RSC4.4T-15/TXG | 6634164 |
