Product SDPL-0404D-1004

Zoom

piconet Coupling Module for PROFIBUS-DP

4 Digital PNP Inputs Filter 3 ms

4 Digital Outputs 0.5 A

Order number: 6824451

Configuration interface
Configurable functions
Supported via I/O‐ASSISTANT 2

Direct connection to the fieldbus
Direct connection to the IP link
Fibre-glass reinforced housing
Encapsulated module electronics
Metal connector
Degree of protection IP67

Hide All Open All

Specifications
Download
Accessories
CAD

General data

EAN	4047101181715
eCl@ss-Code (V5.1.4):	27250313 -/- Communication interface, passive
Customs tariff number	85176200000
Country of origin	DE
Weight	298 g

Technical Data

Ambient temperature	0…+55 °C
Protection class	IP67

Data Sheets

German	433 KB
English	432 KB
French	433 KB
Spanish	433 KB
Czech	432 KB
Dutch	432 KB
Romanian	432 KB
Russian	723 KB
Polish	434 KB
Chinese	529 KB
Turkish	433 KB

CAD File

2D (DWG)	343 KB
3D-1 (STP)	896 KB

Configuration File

GSD	42 KB

General Catalog

Factory Automation Products	43634 KB

Manual

piconet I/O modules	5704 KB
piconet Manual for PROFIBUS-DP	3721 KB

Product Flyer

piconet system overview	752 KB

Product Overview

Modular I/O Systems and Compact I/O Modules in IP20 and IP67	1559 KB
excom I/O system	6454 KB

Quick Start Guide

IP-Link connector	86 KB

Mounting accessories

	TL50BLGYRWALSQ	3800780
	PKG4S-1.5-PSW4S/TXL	6627938
	PS040V-304-2UPN8X-H1141	6833457
	RKS4.5T-1.5-RSS4.5T/TXL	6627733
	RSSX-RSSX-8814-60M	100041128

Functional accessories

	RKC5T-5/TXY	6629770
	QS30LV	3072605
	WKCV-FBY48BU-30M/5D	8900453
