Product PCT R21 50/5A 1.25VA Kl. 1
Interface for DeviceNet™
Order number: 100049784- DIP switch for adjustment of the node address
- Protection class IP20
- 2 x end brackets BL20-WEW35/2-SW
- 1 x end plate BL20-ABPL
- 1 x open style connector
- Integrated power supply
- LEDs for display of supply voltage, group and bus errors
- Gateway between the BL20 system and DeviceNet
- 125 / 250 / 500 kbps
- Connection to DeviceNet™ established via Open-Style connector
General data
| EAN | 4047101664164 |
| eCl@ss-Code (V5.1.4): | 27250312 -/- Communication interface, active |
| Customs tariff number | 85043129900 |
| Country of origin | DE |
| Weight | 202 g |
Technical Data
| Ambient temperature | 0…+55 °C |
| Protection class | IP20 |
Data Sheets
| German | 185 KB |
| English | 184 KB |
| French | 185 KB |
| Spanish | 183 KB |
| Czech | 185 KB |
| Dutch | 184 KB |
| Romanian | 184 KB |
| Russian | 249 KB |
| Polish | 185 KB |
| Chinese | 259 KB |
| Turkish | 198 KB |
Approval
| FM07 ATEX 0040X | 739 KB |
| IECEx FME 07.0004X | 251 KB |
| FM Class 1 Div. 2 US | 178 KB |
| FM Class 1 Div. 2 Canada | 179 KB |
| EU Declaration of Conformity | 136 KB |
CAD File
Configuration File
Firmware
General Catalog
Manual
Manufacturer's Declaration
Product Overview
Mounting accessories
|
RSSD-RSSD-4422-0.5M | 6635819 |
